LC 1.25g Sfp Optical Transceiver Fiber Optic Module For 40km Transmission

Name: LC 125g Sfp Optical Transceiver Fiber Optic Module For 40km Transmission
Brand: Sopto
Price: 10.3 USD

China LC 1.25g Sfp Optical Transceiver Fiber Optic Module For 40km Transmission wholesale

Brand Name : Sopto

Model Number : 1.25G

Certification : ISO9001 / CE / RoHS

Place of Origin : China Shenzhen

MOQ : 1pcs

Price : 10.3usd

Payment Terms : T/T; L/C; Paypal

Delivery Time : 3-5 working days

Packaging Details : 0.024 kg/pcs

Wavelength : 1550nm

Fiber type : SM

Operating temperature : Commercial 0 to 70℃

Application : Gigabit Ethernet

Distance : 40KM

Connector : LC

Date rate : 1.25G

Contact Now

LC 1.25g Sfp Optical Transceiver Fiber Optic Module For 40km Transmission

Features

l Data-rate of 1.25Gbps operation

l 1550nm DFB laser and PIN photo detector for 40km transmission

l Compliant with SFP MSA and SFF-8472 with duplex LC receptacle

l Digital Diagnostic Monitoring: Internal Calibration or External Calibration

l Compatible with SONET OC-24-LR-1

l Compatible with RoHS

l +3.3V single power supply

Applications

l Gigabit Ethernet

l Fiber Channel

l Switch to Switch interface

l Switched backplane applications

l Router/Server interface

l Other optical transmission systems

LC 1.25g Sfp Optical Transceiver Fiber Optic Module For 40km Transmission

Ordering Information

PN	Data Rate	Distance	Fiber	Output Power(dBm)	Sensitivity(dBm)	Interface	Temp.	DDM
Gigabit Ethernet/1XFibre Channel/1.25Gbps
SPT-P551G-S5D	1.25Gbps	550M	MM	-9～-3	-18	Duplex LC	0 to 70℃	D
SPT-P131G-02D	1.25Gbps	2KM	SM	-9～-3	-24	Duplex LC	0 to 70℃	D
SFP-P131G-20D	1.25Gbps	20KM	SM	-9～-3	-24	Duplex LC	0 to 70℃	D
SFP-P551G-40D	1.25Gbps	40KM	SM	-3～0	-24	Duplex LC	0 to 70℃	D
SPT-P551G-60D	1.25Gbps	60KM	SM	-3～0	-27	Duplex LC	0 to 70℃	D
SPT-P551G-80D	1.25Gbps	80KM	SM	-3～0	-27	Duplex LC	0 to 70℃	D
SPT-P551G-100D	1.25Gbps	100KM	SM	0～3	-27	Duplex LC	0 to 70℃	D
SPT-P551G-120D	1.25Gbps	120KM	SM	>1	-30	Duplex LC	0 to 70℃	D
SPT-P551G-150D	1.25Gbps	150KM	SM	>3	-30	Duplex LC	0 to 70℃	D
